| Gain (max.) |
+8dB (Line)
+55dB (Phono MM) |
| Input Sensitivity |
720mV (Line, Volume = 0dB)
3.1mV (Phono MM, Volume=0dB) |
| Input Impedance |
10K (Line)
47K//100pF (Phono MM) |
| Total Harmonic Distortion (THD) |
< 0.0004% (Line, 1KHz @ 2V, Volume = 0dB) |
| Frequency Response |
20Hz-20kHz (+/-0.1dB) |
| Output Voltage |
2.3V max. (Volume = 0dB) |
| Output Impedance |
120Ω |
| Signal-to-Noise Ration (S/N) |
> 110dB (Line, A-weighted)
>76dB (Phono MM, A-weighted) |
| DAC |
|
| D to A converter |
ES9018K2M |
| Total Harmonic Distortion (THD) |
< 0.0006% (1kHz @ 0dBFS) |
| Output level (0dBFS, 1KHz) |
2.05V |
| Max. Sampling Frequency |
192kHz |
| Signal-to-noise ratio (S/N) |
> 112dB (A-weighted) |
| Digital Filters |
Fast Roll-off , Slow Roll-off , Minimum Phase |
| Power Amplifier Section |
|
| Gain |
+29dB |
| Rated Max. Power Output |
2 X 50W (8Ω, THD<1%)
2 X 75W (4Ω, THD<1%) |
| Frequency Response |
20Hz-20kHz (+/-0.3dB) |
| Input Sensitivity |
720mV |
| Total Harmonic Distortion (THD) |
<0.003% (1kHz @ 40W/8Ω) |
| Signal-to-Noise ratio (S/N) |
> 110dB (A-weighted) |
| Max. Output Current |
9A |
| Headphone Amplifier |
|
| Total Harmonic Distortion (THD) |
< 0.01% (1kHz, 50mW) |
| Output Impedance |
2.35Ω |
| Load impedance |
20-600Ω |
| General |
|
| Standby Power Consumption |
<0.5W |
| Power Requirements |
240V ~ 50 - 60Hz
230V ~ 50 - 60Hz
115V ~ 50 - 60Hz
100V ~ 50 - 60Hz |
| Dimensions (mm) (W x H x D) |
445 x 80 x 330mm including feet, terminals and controls |
| Carton Size (mm) (W x H x D) |
512 x 467 x 146 |
| Weight |
7.8kg (Net) |
